Function
IC/RFID card read/write,magnetic card read
Online Inquiry
Inquiry Content：
TTCE-R600
Technical Specifications
Cards type
IC card: ISO7816-1、2、3、4 standard
Support T=0,T=1 CPU Card
Support T=0,T=1 PSAM Card
Contactless card：ISO/IEC 14443 Type A & Type B
Support Mifare 1 S50,S70,UL card,
Mifare Plus,Mifare DesfireMagnetic card:ISO7810，ISO7811 －(1-6)，ISO7812，ISO7813 And ISO15457
Card specification
Material：Paper card and PC card
Width:54 ± 0.5 mm(W) Length : 85 ± 0.5 mm
Thickness: 0.76 ～0.9 mm
Operation distance
≤3cm
Power supply
DC5V
Operation current
Idle:<160mAPeak:<250mA
Interface
USB HID/RS232
Environmental conditions
Operation Temp：0℃ to 50℃
Operation Humi：20～80% （Relative Humidity）
Life time
Magnetic head：800,000cycles
IC card contact：300,000cycles
Certified
Weight
